Vertical Autoclave Deluxe Manufacturer for Destruction of Micro-organisms
Vertical Autoclave Deluxe Specification
Acmas Technologies offer Vertical Autoclave Deluxe mostly used for destruction of living microorganisms andis an ideal Sterilization Equipment for laboratories, hospitals, nursing homes etc. The operating range of these chambers is adjustable and comprise of a control panel. The outer chamber is made of thick stainless sheet whereas the inner chamber includes grade stainless lid. The supporting rings and legs are also made up of stainless steel and the drain valve, as a part of the equipment facilitates easy cleaning of the chamber. Vertical autoclave manufacturers produce energy efficient heaters as per industrial grade which help to reduce the power bills drastically. In addition, the internal joints are carefully welded and polished.The inside and outside wall is developed with high-quality stainless steel. The well-built sheet lid is also developed with high-standard stainless steel. The part is fully developed with very well-organized radial security system that is also created by stainless steel covered along with paddle lifting tool. It is supplied with stainless steel storage bin. The component is fixed with security device, pressure liberate device, water-level meter, cord and plug.
|
Depth mm X Dia mm |
Volume |
|
250mm X 450mm |
22 Ltrs |
|
300mm X 500mm |
35 Ltrs |
|
350mm X 550mm |
52 Ltrs |
|
450mm X 600mm |
95 Ltrs |
|
550mm X 750mm |
178 Ltrs |
Vertical Autoclave Deluxe
Model No : ATI - 102
| Model No. | ATI-101 |
| Type | Cylindrical |
| Construction | Inner & Outer SS 304 |
| Temperature | 121oC / 134oC |
| Lid | SS plate 304 |
| Radial Locking System | Mild Steel |
| Ring | Mild Steel |
| Pressure | 5 to 20 psi |
| Pressure for sterilization process | 1.26 Kgf /cm2 (15psi) |
| Hydro test Pressure | 2.5 Kgf /cm2 ( 35 psi ) |
| Heating Elements | ISI Marked |
| Air Insulation | 75 mm |
| Vacuum Breaker | Inbuilt |
| Water outlet valve | Inbuilt |
| Water level indicating gauge glass with metal guard | Inbuilt |
| Double safety radial locking arrangement. | Inbuilt |
| Gasket | Made of Silicon |
| Automatic Pressure Control Switch | Optional |
| Low Water Cut of Device | Optional |
| Digital temperature control cum timer cum alarm system | Optional |
| Safety Valve | Inbuilt |
| Steam Release Valve | Made of Brass |
| Pressure Gauge | Inbuilt |
| Electrical Control Box | Inbuilt |
| Foot Lifting Device | Inbuilt |
| Basket | Inbuilt |
| Power Supply | 220-230 V, Single Phase |
